32G SFP28 ER 1310nm 40KM LC Optical Transceiver

Product Model:
ESP313X-40D(I)
Data Rate:
32G
Wavelength:
1310nm
Distance:
40km
Connector:
LC
Fiber Type:
SM
DDM:
Yes
Product Origin:
China
Shipping Port:
Shenzhen
Brand:
ETU-LINK
Goods Stock:
100

Duplex LC interface and hot-pluggable design, it integrates a cooled DFB laser and high-sensitivity APD receiver to overcome chromatic dispersion and attenuation challenges.

Lead Time/Contact Us Datasheets

Product Detail

32G SFP28 ER 1310nm 40KM LC Optical Transceiver is an extended-reach, high-performance optical module designed for demanding long-haul communication applications. Operating at a 1310nm wavelength over standard single-mode fiber (SMF), it supports data rates of up to 32Gbps, making it ideally suited for 32G Fibre Channel requiring extended connectivity.

This transceiver achieves a significant transmission distance of up to 40 kilometers, providing an optimal solution for metro network extensions, campus backbones, and distributed data center interconnects.

Featuring a hot-pluggable SFP28 form factor and duplex LC interface, it ensures seamless integration with existing network equipment while delivering superior performance with enhanced receiver sensitivity and industrial-grade temperature tolerance. The module's robust design and high power budget make it a reliable choice for high-bandwidth, long-distance optical links in challenging operational environments.

PRODUCT FEATURES

Up to 28.05Gb/s data links
1310nm DFB laser and APD receiver
Up to 40km on 9/125um SMF
Hot-pluggable SFP footprint
Digital diagnostic capabilities
Class 1 laser safety certified
Cost effective SFP28 solution, enables higher port densities and greater bandwidth
RoHS compliant and lead-free
Single +3.3V power supply
2-wire interface for management specifications compliant with SFF-8472 digital diagnostic monitoring interface for optical transceivers
All-metal housing for superior EMI performance
Case operating temperature: Commercial:0~ +70℃ Extended:-10~ +80℃ Industrial:-40~ +85℃
